Hlau rau Hlau sealing npauj npaim valve

GYPYD363H nyuaj cuam tshuam nyuaj vuam npauj npaim valve isoptimized los ntawm peb cov neeg ua haujlwm technical tom qab nqus cov qauv thiab cov yam ntxwv ntawm txawv teb chaws cov khoom zoo sib xws thiab kov yeej cov teeb meem uas twb muaj lawm hauv kev siv cov khoom siv hauv paus, ua rau nws cov kev pab cuam lub neej ruaj khov thiab sealing ntau dua. Lub npauj npaim valve txais lub hauv paus ntsiab lus ntawm peb-dimensionaeccentric tsim, thiab lub sealing khub yog tsim los ntawm ob qho tib si overlapping cone inclined seem. Tom qab tus nqi eccentric ntawm lub valve lub cev thiab lub rooj zaum ntawm lub rooj zaum, lub rooj sib hloov ntawm lub phaj buterly tuaj yeem ua tiav qhov kev sib cuag tam sim ntawd thiab kev sib cais ntawm qhov qhib thiab kaw. Thelabyrinth foob tau txais txiaj ntsig los ntawm cov qauv aminated ntawm buterly phaj seaing nplhaib hlau thiab graphite, uas tuaj yeem tsis tsuas yog txo qhov hloov pauv torgue oithe valve, tab sis kuj ua kom lub sealing kev ua tau zoo ntawm buterly valve Pressure buterly valve txais yuav txo qis eccentricity tus nqi thiab txhim kho lub zog ntawm npauj npaim phaj, valve ncej zero thiab tawm qhov hluav taws xob ntawm qhov hluav taws xob. valve.

Cov yam ntxwv ntawm tus qauv

1. Compact qauv, me me, lub teeb yuag, hloov tau yooj yim, siv tau yooj yim;

2. Peb-dimensional eccentric multi-layer hard sealing qauv yog saws, thiab nws sealing kev ua tau zoo yog txhim khu kev qha thiab ncav cuag xoom to;

3. Lub valve tsis muaj flange, uas coj kev yooj yim thiab kev zoo nkauj rau cov rwb thaiv tsev thiab qhwv ntawm cov kav dej; 4. lt muaj cov yam ntxwv ntawm hiah kub, hiah siab, corrosion kuj thiab hnav tsis kam.

Tus qauv ua tiav

Tsim thiab Tsim: GB / T12238, JB / T8527

Vuam loj: GB / T12224

Qhov ntev: GB / T122

Kev kuaj thiab tshuaj xyuas: GB / T13927, JB / T9092

Kev ua haujlwm ntsuas

Qhov ntsuas kub: Carbon steel: -29 ℃ ~ 425 ' ℃ Stainless hlau: -409C ~ 600 °

Daim ntawv kis tau tus mob: worm tsav, pneumatic tsav, hluav taws xob tsav, hvdraulic tsav

Khoom Ntev
